MACGREGOR 26M SPECIFICATIONS

Length overall

25'  10

Waterline length

23'  2"

Width (Beam)

7’ 9"

Draft, board up

12"

Draft, board down

5’ 9"

Engine capacity

5 to 70* h.p.

Speed, 70* hp outboard

24 mph

Water ballast

1150 lbs

Permanent ballast 300 lbs

Boat weight, empty

2550 lbs

Trailer weight

530 lbs

Mainsail

170 sq. ft

Jib (100%)

130 sq. ft.

Main and jib

300 sq. ft.

Genoa (150%)

206 sq. ft

Cruising spinnaker

350 sq. ft

Fresh water capacity

5 gallons

Fuel capacity

24 gallons

Mast height above deck

30’

Mast height above water 35'

Cabin headroom

6'

Berths (sleeps 6)



2 doubles

2 singles

Sails

Doyle

Winches

Lewmar




 *70hp max engine only if installed by authorized MacGregor dealer,

 otherwise 50 hp maximum.
